Home  >  HVAC/R Components  >  Surge Protection  >  Disconnect w/Surge  > 60A NF DISCONNECT W/SURGE

60A NF DISCONNECT W/SURGE

No. of Poles 2 Type Side Open A/C Disconnect Amp Rating 60 Amp Fused or Non-Fused Non-Fused Color Gray Voltage Rating 240 Width (in.) 5.00 Side or Top Open Side Enclosure Material CRS Anti-UV Powder Coated Steel Depth (in.) 3.00 Outlet - GFI No Phase Single Standards UL approved for US, not cUL approved for Canada NEMA Enclosure Rain proof, NEMA 3R Enclosure Height (in.) 8.375 NOTE Features integrated surge pull-out
Item #: 83925

MARS Side Open Disconnect with Surge Pull-Out

  • Features a pull-out with integrated surge protection
  • 60 Amp Non-Fused
  • Easy as Wiring a Standard Disconnect
  • External Green & Red LED Status Indicators visible thru a window
  • NEMA 3R Rainproof Enclosure
  • Patent Pending
  • UL Listed, UL 1449 4th Edition

Safety Switch

No. of Poles
2
Type
Side Open A/C Disconnect
Amp Rating
60 Amp
Fused or Non-Fused
Non-Fused
Color
Gray
Voltage Rating
240
Width (in.)
5.00
Side or Top Open
Side
Enclosure Material
CRS Anti-UV Powder Coated Steel
Depth (in.)
3.00
Outlet - GFI
No
Phase
Single
Standards
UL approved for US, not cUL approved for Canada
NEMA Enclosure
Rain proof, NEMA 3R Enclosure
Height (in.)
8.375
NOTE
Features integrated surge pull-out
